Welcome

M5 Engineering (Thailand) Co. Ltd. was established in 2013 to represent MAGMA in Thailand. We provide solutions to foundries, improve quality and optimize the complete foundry process in using MAGMA casting process simulation. We are here to support You... For more information please contact us.

About MAGMA

MAGMA is a world-wide leading developer and supplier of software for casting process simulation.



The name MAGMA stands for robust and innovative casting solutions as well as a strong partnership with the metal casting industry. By combining casting process knowledge with simulation competence, MAGMA partners with our customers to use our expertise to their advantage in the profitable optimization of castings and casting processes. With a commitment to casting excellence, we actively work with our customers to integrate the progressive technology of simulation into their operations. MAGMA’s product and service portfolio includes the powerful, modular simulation software MAGMASOFT ®, with the newest release MAGMA 5, as well as engineering services for casting design and optimization.........

New Release MAGMASOFT® 5.5
Implementation


Working effectively with MAGMASOFT® 5.5 provides the infor­mation you need for your decisions faster and in a more targe­ted manner. The new usability improvements help you to make your daily work with MAGMASOFT® even more efficiently.





We are "M5 Engineering Thailand"
What services we can provide?

Contact us:

Hotline / Line@ : @magma_thailand

Mobile:+66(0) 86 4108165

Email: info@m5engineering.co.th

New Release MAGMASOFT® 5.5

Benefits for Users and Decision Makers – the New MAGMASOFT® 5.5

With the release of MAGMASOFT® 5.5, you can look forward to innovative new capabilities. Efficient casting development, reliable starts of production and robust process windows – numerous new options in the release 5.5 allow for creating even more value in casting design, in toolmaking and in the foundry. Particular emphasis has been placed on further simplified and efficient use of the software and its results.

Thermal convection during solidification influences the feeding behavior


Cast Iron in Motion

Completely new capabilities are available to iron foundrymen to consider the effects of metallurgy and metal treatment on solidification and feeding behavior. With the innovative SMAFEE feeding algorithm, the influence of melt quality, inoculation practice and local pressure distributions on porosity development is even better taken into account. In addition, thermal convection during solidification is now calculated as a standard for iron castings. The impact of the flow on the resulting temperature profile influences the feeding behavior both, large castings and in series production.



The “heart” of the optimized MAGMAIron module is the SMAFEE feeding algorithm. Pressure differences in the metal are created through the combination of metallostatic pressure, local austenite shrinkage and graphite precipitation and the rigidity of the mold. The software calculates local metal transport in partially solidified regions of the casting and the resulting ability to feed the solidifying iron. Thus, both metal quality and inoculation state influence feeding and shrinkage formation in the casting.



The new feeding model is available for all types of cast iron: Grey, ductile and compacted graphite iron.




Direct evaluation of different casting defects in comparison with CT
(Blue: Entrapped  air / Red: shrinkage porosities)

Quality Assessment in Die Casting

In high pressure die casting, casting defects due to entrapped air combined with shrinkage porosities are major causes for scrap. Tooling and process design therefore focus very strongly on reducing porosity due to entrapped gases and shrinkage. The mass balance of air in the cavity and the transport of entrapped air can reliably predicted using MAGMASOFT® 5.5. In the new “Air” result, the amount of air in the cavity and in the melt is visualized quantitatively and allows complete assessment over the entire filling process. It is possible to consistently evaluate the quality of the tooling design and the process conditions over the course of a project, even under changing situations. The corresponding masses of air and well as the effectiveness of the venting conditions can be quantitatively tracked over time using calculated curves.

In addition the prediction of feeding during the intensification phase has been improved. Thus, for the first time, all potential defects in the casting (Caused by both air entrapment and shrinkage porosity) can be evaluated using a single result. This also allows a direct comparison with CT measurements.




MAGMA User Group Meeting 2019


VTR >> "MAGMA User Group Meeting 2019."

M5/MAGMA User Group Meeting 2019 (Thailand)

Again... thanks to everybody who attended this years UGM in Thailand. Besides the user presentations from the automotive industries we are glad to introduce some more information's and projects we did in the jewelry industries. Industry 4.0 is a hot topic in Thailand and your contributions showed that we are moving towards it...!
